27 / 220
18V LXT
Concrete Tools
STANDARD EQUIPMENT INCLUDES:
DHR400T2N:
Two18V (5.0Ah)Li-IonBatteries
BL1850B (196675-2),DualPortRapidCharger (DC18RD),StraightSideHandle (123138-5),
D-StyleSideHandle (196792-8),CleaningCloth (443122-7),BitGrease (194683-7),DepthGauge (331955-1),PlasticCarryingCase (821746-3)
DHR400ZKN:
Tool Only. Batteries and Charger Sold Separately.
Straight Side Handle (123138-5), D-Style Side Handle (196792-8),
Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (331955-1), Plastic Carrying Case (821746-3)
1-9/16" Rotary Hammer with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Capacities:
Concrete (TCT)
1-9/16" (40 mm)
Concrete (Core Bit)
4-1/8" (105 mm)
Impact Energy
11.4 J (8.4 ft. lbs)
No Load Speed
250 - 500 RPM
Blows Per Minute
1,450 - 2,900 BPM
Overall Length
18-5/8" (473 mm)
Net Weight
15.0 lbs (6.8 kg)
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
SDS-MAX Shank / Hammer & Rotation / Hammer Only
• Advanced Anti-Vibration Technology (AVT
TM
) system incorporates vibration absorbing housing, active
dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly
reduced transmission to the operator
• 2 Operating Modes: Rotation / Rotation + Hammer
DHR400T2N
STANDARD EQUIPMENT INCLUDES:
DHR264Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)
DHR263Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle(158057-6), Cleaning Cloth (443122-7),
Bit Grease (194683-7), Depth Gauge (324219-0)
Makita's FIRST 18Vx2 Direct 1" Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck (DHR264Z Only)
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• One touch sliding chuck enables quick and
easy bit changes
1" Rotary Hammers
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Capacities:
Concrete
1" (26 mm)
Steel
1/2" (13 mm)
Wood
1-1/4" (32 mm)
No Load Speed
0 - 1,250 RPM
Blows Per Minute
0 - 5,000 BPM
Impact Energy
3.0 J (2.2 ft. lbs)
Overall Length
14-3/4" (374 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR264Z (with Quick Change Drill Chuck)
DHR263Z
Variable
Speed,
Reversible
Quick Change Drill Chuck
194079-2
STANDARD EQUIPMENT INCLUDES:
DHR242RTJ:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC),
Battery Cover (450128-8), Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)
DHR242Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8" (328 mm)
Net Weight
6.0 lbs (2.7 kg)
Variable
Speed,
Reversible
Lightweight, 3-Mode Rotary Hammer
SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC motor with high power to weight and size ratio
• Quickly attaches to Makita's DX01 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX01 sold separately)
• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to
terminal breakage or poor electrical contact
• 40 angle bit positions enable chisels to be positioned
at optimum angle of operation
DHR242RTJ
DHR202Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• LED Light with Afterglow feature
Variable Speed, Reversible
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1" (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
14-1/8" (358 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR241RMJ
STANDARD EQUIPMENT INCLUDES:
DHR241RMJ:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)
DHR241RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141643-0)
DHR241Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
Variable Speed, Reversible
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs)
No Load Speed
0 - 1200 RPM
Blows Per Minute
0 - 4000 BPM
Overall Length
16-3/8" (417 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR241Z
DHR241RFE
DHR242Z
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Variable
Speed
DHR400ZKN
25
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
DHR165Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• Easily accessible forward / reverse switch for operator convenience
• Electric brake stops bit rotation immediately for maximum operator safety
• 2 operating modes: Rotation / Rotation + Hammer
• One touch SDS-PLUS sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
5/8" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8" (16 mm)
Steel
1/2" (13 mm)
Wood
15/16" (24 mm)
Impact Energy
1.3 J (1 ft. lbs)
No Load Speed
0 - 1,600 RPM
Blows Per Minute
0 - 5,300 BPM
Overall Length
11-3/4" (297 mm)
Net Weight
4.2 lbs (1.9 kg)
