197 / 220
OUTDOOR
Power Equipment
EA3501SRDB
STANDARD EQUIPMENT INCLUDES:
16" Guide Bar (165202-6), 16" Chain (196444-1), Chain Cover 14"-16" (419560-5), Spike Bar (346301-5),
Universal Wrench 13/16 (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)
16" / 35cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
16" / 35cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35cc (2.1 cu.in)
Chain Pitch / Gauge
3/8" / 0.050"
Maximum Engine Speed 13,100 RPM
Power Rating
1.7 kW / 2.3 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
290 ml
Net Weight: Dry w/o Bar & Chain
9.9 lbs (4.5 kg)
Intelligent Ignition Coil
+ Easy Start
EA3201SRDB
STANDARD EQUIPMENT INCLUDES:
16" Guide Bar (165202-6), 16" Chain (196444-1), Chain Cover 16" (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)
16" / 32cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
Intelligent Ignition Coil
+ Easy Start
16" / 32cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
32cc (1.95 cu.in.)
Chain Pitch / Gauge
3/8" / .050"
Maximum Engine Speed 12,800 RPM
Power Rating
1.35 kW / 1.8 HP
Fuel / Oil mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
9.4 lbs (4.2 kg)
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
195
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
16" / 18Vx2 LXT Cordless Chainsaws with
Specialized Battery Positioning for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute) Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita Industry Game Changer within the Cordless Product line
offering Premium Balance, Control and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed
• Variable Speed Trigger Switch (0 - 3,940 FPM) operates the same as a Gasoline Chainsaw
• Built-in LED On / /Off Switch with Auto Power-Off function; for Extended Battery Life
• Front Hand Guard Chain Brake for Operator Safety in case of Accidental Kickback
• Low Noise Level at only 87.7 dB(A) and Zero Emissions
for Operator Comfort
DUC405Z, DUC400Z
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
16" (400 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed
0-3,940 FPM (0-1 200 m/min)
DUC405Z:
Overall Length
31-1/2" (800 mm)
Net Weight
9.0 lbs (4.1 kg)
DUC400Z:
Overall Length
32-1/4" (818 mm)
Net Weight
9.3 lbs (4.2 kg)
Brushless
Motor + XPT +
3 Year Limited
Warranty
16" / 18Vx2 LXT Cordless Chainsaws
14" / 18Vx2 LXT Cordless Chainsaws with
Specialized Battery Positioning for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute) Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita Industry Game Changer within the Cordless Product line
offering Premium Balance, Control and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed
• Variable Speed Trigger Switch (0 - 3,940 FPM) operates the same as a Gasoline Chainsaw
• Built-in LED On / /Off Switch with Auto Power-Off function; for Extended Battery Life
• Front Hand Guard Chain Brake for Operator Safety in case of Accidental Kickback
• Low Noise Level at only 87.7 dB(A) and Zero Emissions
for Operator Comfort
DUC355Z, DUC353Z
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
14" (350 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed
0-3,940 FPM (0-1 200 m/min)
DUC355Z:
Overall Length
30" (762 mm)
Net Weight
8.9 lbs (4.0 kg)
DUC353Z:
Overall Length
30-1/2" (773 mm)
Net Weight
8.9 lbs (4.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
14" Chain (196741-5),
14" Guide Bar (165246-6), Chain Cover (419288-5), Spike Bumper (347078-5),
Box Wrench (782027-9), Oil Supply (182229-1)
DUC355Z
with Captive Bar Nuts
Brushless
Motor + XPT +
3 Year Limited
Warranty
14" / 18Vx2 LXT Cordless Chainsaws
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3),
16" Guide Bar (165247-4), Chain Cover (419242-9), Spike Bumper (347078-5),
Box Wrench (782027-9), Oil Supply (182229-1)
DUC405Z
with Captive Bar Nuts
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover
(419242-9), Oil Supply (182229-1), Spike Bumper (347078-5)
DUC400Z
with Toolless Chain
Tension Adjustment
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
14" Chain
(196741-5), 14" Guide Bar (165246-6), Chain Cover (419288-5),
Spike Bumper (347078-5), Oil Supply (182229-1)
DUC353Z
with Toolless Chain
Tension Adjustment
