GD0602
METALWORKING
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DIE GRINDERACCESSORIES
Part No.
Description
For Model(s)
763625-8
1/4" Collet Cone
GD0603, GD0601, GD0600, 906
763626-6
1/8" Collet Cone
763664-8
Collet Nut
GD0601, GD0600, GD0603
763606-2
Collet Nut
GD0603, 906
763672-9
1/8" Collet Cone
DGD800
763673-7
1/4" Collet Cone
763668-0
Collet Nut
DGD800
192986-3
1/4" Collet Cone / Nut Set
GD0800C, GD0810C
192987-1
1/8" Collet Cone / Nut Set
763645-2
Collet Nut
741616-9
1/4" Cone Wheel Point
GD0603, GD0600, GD0601, GD0800C
GD0810C, DGD800, 906
741617-7
1/4" Flat Wheel Point
CARBIDE BURRS
Head Shape
Head Dimensions
(Diameter x Length)
Shank
Length
Shank
Diameter
Cut Type
Application
Max.
RPM For Model(s)
Part No.
SA
3/8" x 3/4"
1-3/4"
1/4"
Round
Standard
Steel, Stainless Steel & Ferrous Metals
≤ 33,000
RPM
GD0600
GD0601
GD0800C
GD0801C
GD0810C
GD0811C
B-52962
Diamond Cut
B-52978
Non-Ferrous
Aluminum, Non-Ferrous Metals
B-52984
SC
3/8" x 3/4"
Standard
Steel, Stainless Steel & Ferrous Metals
B-52990
Diamond Cut
B-53001
Non-Ferrous
Aluminum, Non-Ferrous Metals
B-53017
SF
3/8" x 3/4"
Standard
Steel, Stainless Steel & Ferrous Metals
B-53023
Diamond Cut
B-53039
Non-Ferrous
Aluminum, Non-Ferrous Metals
B-53045
SL
3/8" x 1"
Standard
Steel, Stainless Steel & Ferrous Metals
B-53051
Diamond Cut
B-53067
Non-Ferrous
Aluminum, Non-Ferrous Metals
B-53073
SM 3/8" x 3/4"
Standard
Steel, Stainless Steel & Ferrous Metals
B-53089
Diamond Cut
B-53095
Non-Ferrous
Aluminum, Non-Ferrous Metals
B-53104
STANDARD CUT BURRS
quickly remove stock for maximum
grinding efficiency
DIAMOND CUT BURRS
offer reduced vibration for smoother
handling and reduced operator fatigue
NON-FERROUS CUT BURRS
cut broadly and prevent clogging when
working with soft non-ferrous materials
GD0602
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763673-7),Two Wrenches 13 (781039-9)
Light Weight And Slim Housing For Easy Handling
Thumb Switch with Lock-On (AC/DC)
• Compact, short-nose design for maximum comfort and precision when working in tight spaces
• Protective zig-zag varnish seals the motor from dust and debris for longer life
• Round-shaped collet nut reduces the possibility of damage or scratches to workpiece
• High heat resistance
• Vent slots designed to direct air exhaust away from the user
• AC/DC switch for use with alternative power source
1/4" Die Grinder
SPECIFICATIONS
Collet Capacity
1/4" (6.35 mm)
Maximum Wheel Point Diameter
1-1/2" (38 mm)
No Load Speed
25,000 RPM
AMPS (120V)
3.5 A
Overall Length
10-3/8" (264 mm)
Net Weight
3.1 lbs (1.4 kg)
Anti-Slip Rubber Cover,
AC/DC
Collet Cone
Collet Nut
Cone
Wheel Point
Flat
Wheel Point
176
