STANDARD EQUIPMENT INCLUDES:
GA6010:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel
(1 Ea.A-95978-25), Inner Flange (224361-6), Lock Nut (224568-4)
GA6010Z:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel
(1 Ea.A-95978-25), Lock Nut (224568-4)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left
or right side of tool
6" Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.0 lbs (2.7 kg)
Trigger Switch with
Lock-On
Button (AC/DC)
GA6010
Trigger Switch with
No Lock-On
Button (AC/DC)
GA6010Z
STANDARD EQUIPMENT INCLUDES:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Tool-less Wheel Cover (123146-6), 6" Depressed Center Wheel (1 Ea. A-95978-25),
Inner Flange (224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Two Stage Safety Trigger Switch (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
SJS Technology, Electric Brake
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.6 lbs (3.0 kg)
GA6020Y
STANDARD EQUIPMENT INCLUDES:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (135110-5), 6" Depressed Center Wheel (1 Ea.A-95978-25),
Inner Flange (224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Trigger Switch with No Lock-On Button (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
SJS Technology, Electric Brake
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.6 lbs (3.0 kg)
GA6020
STANDARD EQUIPMENT INCLUDES:
9566PC:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Centre Wheel
(A-95978), Inner Flange (224361-6), Lock Nut 5/8"-45 (224568-4)
9565PCV:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Centre Wheel
(A-95978), Inner Flange (224361-6), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left
or right side of tool
6" Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Diamond Wheel
6" (150 mm)
Wire Cup Brush
4" (102 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
13.0
Overall Length
12-1/8" (307 mm)
Net Weight
5.5 lbs (2.5 kg)
9566PCV
9566PC
Variable Speed
(9566PCV Only)
SJS
Technology
STANDARD EQUIPMENT INCLUDES:
7" Depressed Center Wheel (D-20806), Side Handle (152539-0), Inner Flange (224317-9), Lock Nut (224568-4), Lock Nut Wrench 28
(782412-6),Toolless Wheel Cover ( 122772-8)
Paddle Switch with Lock-On Button (AC)
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Electronic Current Limiter,
Soft Start
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,400 RPM
AMPS (120V)
15.0 A
Overall Length
17-7/8" (453 mm)
Net Weight
9.5 lbs (4.3 kg)
GA7010C
STANDARD EQUIPMENT INCLUDES:
Side Handle (152539-0), Lock Nut Wrench 28 (782412-6), Wheel Cover (122939-8), Inner Flange (224317-9), Lock Nut (224568-4)
Paddle Switch with Lock-On Button (AC/DC)
• Compact gear housing increases maximum cutting depth by 1/4"
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
17" (432 mm)
Net Weight
9.9 lbs (4.5 kg)
GA7050
