50 / 220
12VMAXCXT
Power Tools
makita.ca
48
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DF033DWYE
STANDARD EQUIPMENT INCLUDES:
DF033DWYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF033DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Improved ball bearing anvil holder reduces bit wobbling and vibration for cleaner, more accurate
drilling and fastening
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 250 in. lbs. of torque
1/4" Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
Capacities:
Steel
3/8" (10 mm)
Wood
13/16" (21 mm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,700 RPM
Maximum Torque
250 in. lbs (28 Nm)
Overall Length
5-7/8" (149 mm)
Net Weight
1.6 lbs (0.7 kg)
DF033DZ
Variable 2-Speed,
Reversible
DF032DSYE
STANDARD EQUIPMENT INCLUDES:
DF032DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF032DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 280 in. lbs of torque
• LED job light with pre-glow
and after-glow
feature illuminates
work area
Variable 2-Speed,
Reversible
1/4" Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
Capacities:
Steel
3/8" (10 mm)
Wood
1-1/8" (28 mm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,500 RPM
Maximum Torque
280 in. lbs (32 Nm)
Overall Length
4-7/8" (124 mm)
Net Weight
1.9 lbs (0.88 kg)
DF032DZ
HP332DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5), Phillips Bit 2-50 (784244-7)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• 20 clutch settings deliver up to 280 in. lbs of torque
• Compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry
• 3/8" keyless drill chuck for quick and easy bit changes
• Variable speed trigger allows operator to adjust speed based on materials or application
• Electric brake stops bit rotation immediately for
maximum operator safety
• LED job light with pre-glow / afterglow features
illuminates
drilling area
Variable 2-Speed,
Reversible
3/8" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Concrete
5/16" (8 mm)
Steel
3/8" (10 mm)
Wood
1-1/8" (28 mm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,500 RPM
Blows Per Minute:
Low
0 - 6,750 BPM
High
0 - 22,500 BPM
Maximum Lock Torque 280 in. lbs (32 Nm)
Overall Length
6-5/8" (168 mm)
Net Weight
2.0 lbs (0.9 kg)
HR166DSMJ
STANDARD EQUIPMENT INCLUDES:
HR166DSMJ:
Two 12V MAX (4.0Ah) CXT Li-Ion Batteries
BL1014B (197416-9), Slide Charger (DC10SB), Battery Cover (456128-6),
Side Handle (158057-6), Depth Gauge (415486-9), Interlocking Case (197211-7)
HR166DZ:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (415486-9), Side Handle (158057-6)
Compact eXtreme Technology (CXT)
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Vibration absorbing housing actively counteracts the vibration of the tool for greatly reduced
transmission to the operator
• Brushless DC motor with high power to weight and size ratio
• One touch sliding chuck enables quick and easy bit changes
• LED job light with pre-glow and after-glow feature illuminates work area
5/8" Rotary Hammer
HR166DZ
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Concrete
5/8" (16 mm)
Steel
3/8" (10 mm)
Wood
1/2" (13 mm)
Impact Energy
1.0 J (0.74 ft. lbs)
No Load Speed
0 - 680 RPM
Blows Per Minute
0 - 4,800 BPM
Overall Length
9-7/8" (250 mm)
Net Weight
4.4 lbs (2.0 kg)
DF031DSYE
STANDARD EQUIPMENT INCLUDES:
DF031DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF031DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 18 clutch settings + drill mode delivers up to 250 in. lbs of torque
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4" Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
Capacities:
Steel
3/8" (10 mm)
Wood
13/16" (21 mm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,700 RPM
Maximum Torque
250 in. lbs (28 Nm)
Overall Length
6-3/16" (157 mm)
Net Weight
2.1 lbs (0.94 kg)
DF031DZ
Variable 2-Speed,
Reversible
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Improved ball bearing anvil holder reduces bit wobbling and vibration for cleaner, more accurate
drilling and fastening
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 250 in. lbs. of torque
• Variable speed trigger allows operator to adjust speed based on materials or application
• LED job light with pre-glow and after-glow feature
illuminates work area
• Ultra-compact design (7-5/8" long)
3/8" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Concrete
5/16" (8 mm)
Steel
3/8" (10 mm)
Wood
13/16" (21 mm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,700 RPM
Blows Per Minute:
Low
0 - 6,750 BPM
High
0 - 25,500 BPM
Maximum Lock Torque 250 in. lbs (28 Nm)
Overall Length
7-5/8" (193 mm)
Net Weight
2.4 lbs (1.1 kg)
HP333DWYE
HP333DZ
Variable 2-Speed,
Reversible
