43 / 220
18V LXT
Metalworking Tools
makita.ca
41
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
DGA506Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
DGA508Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
High Performance
And Efficiency For Heavy-Duty
Grinding Applications
• Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load
condition, enabling rapid movement between
high speed and high torque applications
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and
liquids for optimal performance in
extreme conditions
5
"
Angle Grinders
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5" (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
14-1/4" (362 mm)
Net Weight
4.2 lbs (1.9 kg)
Thumb Switch
with Lock-On,
Electric Brake
DGA506Z
Two Stage Safety
Paddle Switch
Electric Brake
DGA508Z
DGA511Z
5
"
Angle Grinder
High Performance And Efficiency With Variable Speed For Heavy-Duty
Grinding Applications
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden
drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5" (125 mm)
No Load Speed
3,000 - 8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
15" (382 mm)
Net Weight
5.1 lbs (2.3 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Centre Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4)
Thumb Switch with Lock-On,
Variable Speed
DGA455Z
4-1/2" Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
• Automatic Torque Drive Technology
TM
(ADT) feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• LED charge level indicator displays approximate remaining battery power
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
4-1/2" (115 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
14-1/4" (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2" Depressed Center Wheel (D-20781),Toolless Wheel Cover (123144-0),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety
Paddle Switch
DGA454RMEX
4-1/2" Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
• Automatic Torque Drive Technology
TM
(ADT) feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• LED charge level indicator displays approximate remaining battery power
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
4-1/2" (115 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
14-1/4" (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2" Depressed Center Wheel (D-20781),Toolless Wheel Cover
(123144-0), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)
DGA454Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two Wrenches 13 (781039-9), 1/4" Collet Cone (763673-7),
Collet Nut (763668-0)
Compact And Lightweight Die Grinder
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low battery capacity light indicates ideal time to recharge battery
• Vent slots direct exhaust towards opposite side of operator
• Easy to grip motor housing for easier handling
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
• Compact, short-nose design for maximum comfort and precision when working in tight spaces
1/4" Die Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/4" (6.35 mm)
Maximum Wheel Diameter 1-7/16" (36 mm)
No Load Speed
26,000 RPM
Overall Length
12-1/8" (307 mm)
Net Weight
2.5 lbs (1.1 kg)
DGD801Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two Wrenches 13 (781039-9), 1/4" Collet Cone (763673-7),
Collet Nut (763668-0)
Compact And Lightweight Die Grinder
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low Battery Capacity Light indicates ideal time to recharge battery
• Vent Slots direct exhaust towards opposite side of operator
• Easy to Grip Motor Housing for easier handling
• Ergonomic Soft Rubber Grip design
for vibration absorption and
comfortable operation
1/4" Die Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/4" (6.35 mm)
Maximum Wheel Diameter 1-7/16" (36 mm)
No Load Speed
26,000 RPM
Overall Length
15-3/4" (402 mm)
Net Weight
4.4 lbs (2.0 kg)
DGD800Z
Thumb Switch with Lock-On
