All Makita Gasoline Powered Chainsawsnow feature
New HIGH VISIBILITY SAFETY COLOUR!
EA6100PRGE 21" / 60.7cc 2-Stroke Chainsaw
21˝ / 60.7cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and Winter Operation Mode
• SAS / Stratified Air Scavenging System to comply with many exhaust emission regulations
• Easy Start / Equipped with a Spring Assisted Recoil Starter for 30% Less pulling force and Low RPM Ignition Coil providing Faster, Easier Starting
• Heavy Duty Cartridge Filter System designed for Extended Filter Life and Less Maintenance
• Touch & Stop / One Lever Control for Starting, Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening System is engineered for reducing vibration transfer to the operator
• Fuel Primer Bulb for Improved and Quicker Cold Starts
• Aggressive Large Metal Spike Bar for Safety and Hinge Action Cutting
• Half Throttle-lock start position with Easy Start for Reduced Start-Up Force
• Easy Remove Air Filter and Spark Plug Cover for quick maintenance access
SPECIFICATIONS
Displacement 60.7cc (3.7 cu.in.)
Chain Pitch / Gauge 3/8" / 0.058"
Max. Engine Speed 13,800 RPM
Power Rating 3.4 kW / 4.5 HP
Fuel Tank Capacity 800 ml
Oil Tank Capacity 480 ml
Fuel / Oil Mixture 50:1
Net Weight: Dry w/o Bar & Chain 13.2 lbs (6.0 kg)
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 21˝ Guide Bar (443 053 651), Chain Cover (952 020 660),Tool Kit (957 004 002), Spike Bar (130 250 020), Spark Plug (965 603 021), Starter Rope (181 164 020)
SAS + Easy Start
+ Winter Mode
Longlife Air Filter system
'Easy Start' Features
'Touch & Stop' one lever control
EA6100
When QUALITY&SERVICE Counts – ChooseMakita
EA7900PRFE
20" / 78.5cc Environment-Friendly 2-Stroke Chainsaw with
Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler recycles
unburned gas through the exhaust increasing
Operational Efficiency producing much
Cleaner Emissions
• Heavy-duty air filter system for extended air filter life
• Environment-Friendly 2-Stroke Engine in compliance
with: CARB Tier 3, EPA Phase 2 and EU Stage
2 Regulations
• Half Throttle-lock start position with Decompression
Valve for Reduced Start-Up Force
• Winter Mode (Optional) / Prevents
Carburetor Icing by providing
a Higher Operating
Engine Temperature
during Cold Weather
use and up to 5˚C
SLR + Decompression Valve
+ Winter Mode
20" / 78.5cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement 78.5cc. (4.8 cu.in.)
Chain Pitch / Gauge 3/8" / 0.058"
Max. Engine Speed 12,800 RPM
Power Rating 4.4 kW / 5.7 HP
Fuel Tank Capacity 750 ml
Oil Tank Capacity 420 ml
Fuel / Oil mixture 50:1
Net Weight 14.7 lbs. (6.7 kg)
EA7900PRFE
STANDARD EQUIPMENT INCLUDES: 20-21" Chain (523 099 072), 20" Guide Bar (523 099 072), Chain Cover (952 020 660),
Tool Kit (957 004 002), Starter Rope (108 164 020), Spark Plug (965 603 021)
