General Catalogue

Electric

Power Tools

makita.ca

When

QUALITY & SERVICE

Counts – Choose Makita

STANDARD EQUIPMENT INCLUDES:

16-5/16˝ C.T. Blade 32T(A-95093), Hex Wrench 6 (783204-6), Guide Rule (164019-4), Protective Stand Set (194701-1)

Large Capacity For Beam And Timber Cutting

• Powerful Motor delivers 1,800 max. watts out

• Rugged Steel Base for maximum stability

• Electric Brake for increased operator safety

• Blade Stabilizer for stable blade rotation

and superior cutting performance

• Large Depth Control Lever for

convenience and secure adjustments

Electric Brake,

Cutting Capacity of 6-1/4" (158 mm)

16-5/16˝ Circular Saw

SPECIFICATIONS

Blade Diameter

16-5/16˝ (415 mm)

Arbor

1˝ (25 mm)

Maximum Cutting Capacities:

0°

6-1/4˝ (158 mm)

45°

4-3/16˝ (106 mm)

No Load Speed

2,300 RPM

AMPS (120V)

15.0 A

Overall Length

24-1/4˝ (616 mm)

Net Weight

32.2 lbs (14.6 kg)

5402NA

STANDARD EQUIPMENT INCLUDES:

10-1/4˝ C.TBlade 24T (A-94910), Hex Wrench 6 (783204-6), Guide Rule (164367-1), Wrench Holder 5.6 (410047-0)

Ideal For Single Pass Cutting Of 4X Material

• Lock-off button prevents accidental start-up for operator safety

• Lightweight design with magnesium safety cover and blade case

• Diecast aluminum base for maximum operational stability

• Compact blade case with reduced width for enhanced operational versatility

• Rear angular guide allows easy and precise adjustment of bevel angle

• Adjustment screws enable operator to easily square base plate to blade

• Large top handle for easy carrying

• Flat motor housing for stability during

blade changes

• Bevel capacity of 0° - 50°

10-1/4˝ Circular Saw

SPECIFICATIONS

Blade Diameter

10-1/4˝ (260 mm)

Arbor

5/8˝ (15.88 mm)

Maximum Cutting Capacities:

0°

3-13/16˝ (97 mm)

45°

2-11/16˝ (68 mm)

No Load Speed

4,300 RPM

AMPS (120V)

15.0 A

Overall Length

16-1/2˝ (418 mm)

Net Weight

15.2 lbs (6.9 kg)

HS0600

STANDARD EQUIPMENT INCLUDES:

8-1/4˝ C.T. Blade 24T(D-21521), Hex Wrench 6 (783204-6), Guide Rule (164095-8)

High Performance Magnesium Blade Case And Base

• Electric Brake for operator safety

• Dual LED Job Lights illuminate cut line

• Blower feature keeps cutting line free of sawdust

• Bevel Capacity of 50° with Positive Stops at 22.5°, 45°, and 50°

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Cutting Depth Capacity Of 3˝ (75.5 mm)

Electric Brake

8-1/4˝ Circular Saw

SPECIFICATIONS

Blade Diameter

8-1/4˝ (210 mm)

Arbor

5/8˝ (15.9 mm)

Maximum Cutting Capacities:

0°

3˝ (75.5 mm)

45°

2-1/4˝ (57 mm)

50°

2˝ (51.5 mm)

No Load Speed

5,200 RPM

AMPS (120V)

15.0 A

Overall Length

13-1/8˝ (332 mm)

Net Weight

11.2 lbs (5.1 kg)

5008MGA

STANDARD EQUIPMENT INCLUDES:

5007MG & 5007MGA:

7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Hex Wrench 6 (783204-6), Guide Rule (164095-8),

Plastic Carrying Case (158279-8)

High Performance Magnesium Blade Case And Base

• Dual LED Job Lights illuminate cut line

• Blower feature keeps cutting line free of sawdust

• Bevel Capacity of 56° with Positive Stops at 22.5°, 45°, and 56°

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Cutting Capacity Of 2-1/2˝ (63.5 mm)

Electric Brake (5007MGA)

7-1/4˝ Circular Saw

SPECIFICATIONS

Blade Diameter

7-1/4˝ (185 mm)

Arbor

5/8˝ (15.9 mm)

Maximum Cutting Capacities:

0°

2-1/2˝ (63.5 mm)

45°

1-3/4˝ (45 mm)

56°

1-3/8˝ (35 mm)

No Load Speed

5,800 RPM

AMPS (120V)

15.0 A

Overall Length

12-1/2˝ (317 mm)

Net Weight

10.6 lbs (4.8 kg)

5007MG

5007MGA

High Power To Weight Ratio

• Electric Brake for increased operator safety

• Heavy Duty Aluminum Base Plate for

jobsite durability

• LED Job Light with Independent On / Off Switch

• Flat Motor Housing provides stability during

blade changes

• Bevel Capacity of 45°

Cutting Capacity Of 2-3/8˝ (60 mm)

Electric Brake

7-1/4˝ Circular Saws

SPECIFICATIONS

Blade Diameter

7-1/4˝ (185 mm)

Arbor

5/8˝ (15.9 mm)

Maximum Cutting Capacities:

0°

2-3/8˝ (60 mm)

45°

1-3/4˝ (46 mm)

No Load Speed

5,800 RPM

AMPS (120V)

15.0 A

Overall Length

12˝ (305 mm)

Net Weight

11.1 lbs (5.0 kg)

STANDARD EQUIPMENT INCLUDES:

7-1/4˝C.T. Blade 24T(1 Ea.A-94530-10),

Offset Wrench 13 (782016-4), Guide Rule (164095-8),

Plastic Carrying Case (824473-1)

5007FAK

STANDARD EQUIPMENT

INCLUDES:

7-1/4˝ C.T. Blade 24T

(1 Ea.A-94530-10),

Offset Wrench 13 (782016-4)

5007FA

Plastic Carrying Case

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

10-1/4˝ C.T. Blade 24T(A-94910), Hex Wrench 6 (783204-6), Guide Rule (165499-7)

"SJS" Technology Prevents Kickback If Blade Jams, Protecting the

Operator And The Tool

• Electric Brake for increased operator safety

• Lock-Off Button prevents accidental start-up for operator safety

• Diecast Aluminum Base for maximum operational stability

• Compact Blade Case and reduced overall tool height for enhanced operational versatility

• Large Top Handle for easy carrying

• Flat Motor Housing for stability during blade changes

"SJS" Technology, Electric Brake,

Cutting Capacity of 3-3/4" (95 mm)

10-1/4˝ Circular Saw

SPECIFICATIONS

Blade Diameter

10-1/4˝ (260 mm)

Arbor

5/8˝ (15.9 mm)

Maximum Cutting Capacities:

0°

3-3/4˝ (95 mm)

45°

2-3/4˝ (69 mm)

No Load Speed

3,800 RPM

AMPS (120V)

15.0 A

Overall Length

16˝ (405 mm)

Net Weight

20.3 lbs (9.2 kg)

5104

Compatible with optional Makita 55" (194368-5)

and 118" (194367-7) Guide Rails using

Guide Rail Adapter (198566-3) for maximum

cutting ease and precision

Cutting

Capacity

Of 3-3/16"

(97 mm)
