ABRASIVE WHEELS
Wheel Diameter Arbor Thickness Wet / Dry Application Max. RPM For Model(s) Part No.
16" 20 mm 3/16"
Wet / Dry Concrete, Stone, Masonry & Asphalt
4,250 EK8100
966 161 020
Dry Steel & Ferrous Metals 966 161 050
14"
1" 5/32"
Wet / Dry Concrete, Stone, Masonry & Asphalt
5,500
4114, EK7301HD
EK7651HD
966 144 120
Dry Steel & Ferrous Metals 966 144 152
20 mm
5/32" Wet / Dry Concrete, Stone, Masonry & Asphalt EK6101, EK7301
EK7651H
966 141 120
3/16" Dry Steel & Ferrous Metals 966 141 150
12" 20 mm 1/8"
Wet / Dry Concrete, Stone, Masonry & Asphalt 5,400
DPC6430
966 121 120
Dry Steel & Ferrous Metals 6,400 966 121 150
OPTIMUM™ DIAMOND BLADES
Optimum Bond Matrix provides the optimal balance between wear, fracture and exposure in order to maximize the cutting ability of the diamond content
Blade
Diameter Arbor Rim Type Wet /Dry Material Type Application Max. RPM For Model(s) Part No.
16" 1", 20 mm SegmentedRim
Wet or
Dry
Medium Cured Concrete, Block,Brick, Masonry 4,800 EK8100
A-94742
Soft
Asphalt, Green Concrete,
Sand Stone A-94661
14" 1", 20 mm
Turbo Rim
Wet or
Dry
Hard Granite, Ceramic, Stone
5,400
4114
EK6101
EK7301 / HD
EK7651H / HD
A-94627
Segmented
Rim
Medium Cured Concrete, Block,Brick, Masonry A-94736
Medium & Soft
(Dual Purpose) Concrete & Asphalt T-01270
Soft Asphalt, Unset Concrete,
Sandstone A-94655
12" 1", 20 mm SegmentedRim
Wet or
Dry
Medium Cured Concrete, Block,Brick, Masonry
6,300 4112H
DPC6430
A-94720
Medium & Soft
(Dual Purpose) Concrete & Asphalt T-01264
Segmented Rim
Quick Cutting. Ideal for general purpose use in Concrete, Tile, Brick and Stone.
Does not produce as clean a cut as a Turbo or Continuous Rim Blade.
Turbo Rim
Quick and Clean cutting. The ideal combination of a Segmented and Continuous
Rim. Ideal for all applications including tile, brick, gypsum, plaster.
14" 3D PREMIUM DIAMOND BLADE
T-02836
• Features 3D Diamond Grid Technology incorporating even placement
of diamond content throughout the segment
• 3D pattern releases worn diamond and exposes sharp diamond at a consistent rate
• Offers premium professional performance versus traditional diamond blades
• Keyhole expansion slots promotes blade cooling
• Laser welded segments ensure the strongest possible joint
• Segmented style rim
• Ideal for concrete, asphalt, brick and block
PREMIUM PROFESSIONAL
PERFORMANCE
14" METAL CUTTING BLADE FOR POWER CUTTERS
A-96229
• Offers up to 100x the life of abrasive wheels
• Ideal for cutting angle iron, rebar, deck plating, steel studs, pipe and more!
• Premium diamond content for long life and fast cutting
• Expertly balanced premium steel core for reduced vibration and noise
• Vacuum brazed diamond segments for optimum operational life and consistent performance
• Eliminates performance issues of abrasive wheels, including disc
shrinkage, glazing and shattering
• Segmented Rim style reduces heat buildup and maximizes material removal
FASTEST CUTTING
MORE CUTS
FASTEST CUTTING FASTEST CUTTING
MORE CUTS
