General Catalogue

177 / 212

Large capacity
air chamber
for increased
power
AN923
Electric Power Tools
175
When QUALITY & SERVICE Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Hook (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
21° Round Head Framing Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-Off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise when
disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 2˝ - 3-1/2˝
Nail Type .113˝ - .162˝ 21° Round Head
Magazine Capacity 64 - 74 Nails
Dimensions (L x W x H)
22˝ x 4-1/4˝ x 13-11/16˝
(559 mm x 109 mm x 347 mm)
Net Weight 8.6 lbs (3.9 kg)
AN923
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
34° Clipped Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise
when disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type .113˝ - .131˝ 34° Clipped Head
Nail Size 2˝ - 3-1/2˝ 34° Clipped Head
Operating Air Pressure 65-120 PSIG
Magazine Capacity 60 - 84 Nails
Dimensions (L x W x H)
17-7/8˝ x 4-1/4˝ x 14-3/8˝
(455 mm x 109 mm x 365 mm)
Net Weight 8.8 lbs (4.0 kg)
AN943
Uses 34° Clipped Head
Framing Nails
Uses 21° Round Head
Framing Nails
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2)
28° Round or Clipped Head
Framing Strip Nailer
• Large capacity air chamber for increased power
• 2 Mode - Sequential & Bump
• Depth setting knob for adjustment of nailing depth
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip
spikes prevents slipping
Uses 28° Round or Clipped
Head Framing Nails
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type 0.113˝ - 0.131˝, 28° Round Head
Magazine Capacity 60 - 84 Nails
Operating Air Pressure 70-120 PSIG
Nail Size
2-1/2˝- 3-1/2˝, 28° Round or Clipped Head
Dimensions (L x W x H)
17-1/2˝ x 4-31/32˝ x 13-11/32˝
(445 mm x 126 mm x 339 mm)
Net Weight 7.0 lbs (3.2 kg)
AN944
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)
15° Round Head Coil Framing Nailer
• Reduced size for improved handling and optimal maneuverability during operation
• 2 Mode - Sequential, Bump Fire
• 8 depth nailing settings in 1/32˝ increments with adjustment knob
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2˝ Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4˝ - 3-1/2˝ (45 mm - 90 mm)
Nail Type .099˝ - .150˝ 15° Round Head
Magazine Capacity 150 - 300 Nails
Dimensions (L x W x H)
12-1/2˝ x 5˝ x 14-1/4˝
(318 mm x 128 mm x 363 mm)
Net Weight 7.7 lbs (3.5 kg)
AN902
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7)
15° Round Head Coil Roofing Nailer
• Operates in Bump Fire Mode
• 9 Depth Settings with adjustment knob
• Two Housing Guards to protect air chamber
• One-Touch, easy to load magazine
• Quick Release Shingle Guide for easy adjustment on the jobsite
• Rubberized Grip for vibration absorption and comfortable operation
1-3/4˝ Roofing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 7/8˝ – 1-3/4˝ (22 mm - 45 mm)
Nail Type 1/8˝ (3.0 mm) 15° Round Head
Magazine Capacity 120 Nails
Dimensions (L x W x H)
9-5/8˝ x 4-1/2˝ x 10-3/8˝
(245 mm x 114 mm x 265 mm)
Net Weight 5.8 lbs (2.5 kg)
AN451
