Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Diamond Wheel
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 11,000 RPM
AMPS (120V)
12.0 A
GA5042C01:
Overall length 11-7/8˝ (303 mm)
Net Weight
5.5 lbs (2.5 kg)
GA5043C01:
Overall length 12-3/4˝ (325 mm)
Net Weight
5.9 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8)
Inner Flange (224399-1), Lock Nut 5/8-45(224568-4)
GA5042C01
GA5042C01, GA5043C01
5˝ Angle Grinders
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8),
Inner Flange (224448-4), Lock Nut 5/8-45(224568-4)
GA5043C01
Mechanical
Brake
• Powerful 10 amp motor ideal for high
production applications
• Lightweight design reduces operator
fatigue during periods of prolonged use
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
12,000 RPM
AMPS (120V)
10.0 A
Overall Length
14˝ (356 mm)
Net Weight
6.4 lbs (2.9 kg)
9005BY, 9005BZ, 9005B
5˝ Angle Grinders
Two Stage Safety
Trigger Switch
(AC/DC)
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25),
Wheel Cover (123099-9), Side Handle (152492-0)
Inner Flange (224399-1), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005BY
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25),
Wheel Cover (123099-9), Side Handle (152492-0),
Inner Flange (224399-1), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005BZ
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25),
Wheel Cover (123099-9), Side Handle (152492-0),
Inner Flange (224399-1), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005B
Trigger Switch
with No Lock-On
Button
(AC/DC)
Trigger Switch
with Lock-On
Button
(AC/DC)
"SJS" Technology,
Variable Speed
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (1 Ea.A-95962-25), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Wheel Cover (123144-0),
Inner Flange (224399-1), Lock Nut 5/8-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• "SJS" (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
• Rotatable gear housing can be positioned at every 90°
• Advanced dust-proof construction
“SJS” Technology, Variable Speed
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Diamond Wheel
5˝ (125 mm)
Wire Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 10,500 RPM
AMPS (120V)
13.0 A
Overall Length
12-1/8˝ (307 mm)
Net Weight
5.3 lbs (2.4 kg)
9565PCV
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (D-20797), Inner Flange (224399-1),Toolless Wheel Cover (123145-8), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6), Side Handle (158237-4)
Thumb Switch with Lock-On (AC)
• "SJS" (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Labyrinth construction seals motor and bearings from contamination
• Electronic current limiter protects motor from accidental overload
• Thumb switch conveniently located for operator comfort
• Removable side handle can be mounted on left or right side of tool
• Tool-less wheel guard adjustment
“SJS” Technology, Variable Speed,
Electronic Current Limiter
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Diamond Wheel
5˝ (125 mm)
Wire Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 10,500 RPM
AMPS (120 V)
12.0 A
Overall Length
11-3/4˝ (299 mm)
Net Weight
5.3 lbs (2.4 kg)
9565CV
