Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades, Blade Cover (454277-3), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)
5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• 28-3/4" Cutting Length with 3 Edge Tooth Design
and High Anti-Abrasion Coated Surface for
Stain Free Long Lasting Operation
• Double Sided Stainless Steel Blades for
Extended Life, Clean Trimming and Cutting
on Both Sides of Blade
• Extended 50 Hour Long Life Gear Case
Lubrication System offers Minimal Service
Maintenance by circulating grease in the
gear housing.
• 5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• Anti-vibration design for Less
Operator Fatigue
• Forward Facing Exhaust
redirects away from
the operator
28-3/4˝ / 22.2 cc 2-Stroke Hedge Trimmer
SPECIFICATIONS
Displacement
22.2 cc
Maximum Engine Power 0.68 kW / 0.91 hp
Cutting Length
28-3/4˝ (728 mm)
Carburetor
Diaphragm type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
49-1/2˝ (125 cm)
Net Weight
11.4 lbs (5.2 kg)
EH7500W
WHEELBARROWS
18V x2 LXT POWER-ASSISTED
Battery Box Holds Two Selectable 18V Batteries / Operates using (1) 18V Battery at a time
Wheelbarrow with
Flatbed Tray
Removable Sides / DCU180ZX1
Wheelbarrow with
Bucket
Dumping Feature / DCU180ZX2
N
EW
from Makita
Features Extreme Protection Technology (XPT™) to provide increased dust and water resistance in harsh job site conditions
• Delivers up to 60 minutes of run time under load using one 18V LXT (6.0 Ah) BL1860 battery
• Holds (2) 18V LXT Lithium-Ion batteries but operates using (1) 18V battery at a time; utilizes second battery when needed
• Makita-built BL™ Brushless Motor for optimal performance
• 2-speed with maximum speed up to 2.5 MPH on a 12º incline
• Maximum load capacity up to 287 lbs (130 kg)
• 7" mechanical disc brake for faster stopping
• Rear wheel spacing is adjustable from 19" to 30" to accommodate the work environment
• L-shaped legs can be easily installed to replace rear wheels
• L.E.D. lights on each side of frame to illuminate the work area
DCU180ZX1, DCU180ZX2
Power-Assisted Wheelbarrows
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Speed:
Forward, High / Low
0 - 3.5 km/h / 0 - 1.5 km/h
Reverse
0 - 1.0 km/h
Minimum Turning Radius
(Outer diameter when turning with front wheel as axis) 110 cm
Maximum Climbing Capacity
12°
Maximum Load Capacity
287 lbs (130 kg)
DCU180ZX1:
Overall Dimensions during operation (L x W x H)
61-1/2˝ x 41-3/4˝ x 35-1/2˝ (156 cm x 106 cm x 90 cm)
Net Weight
97.5 lbs (44.2 kg)
DCU180ZX2:
Overall Dimensions during operation (L x W x H)
51-1/2˝ x 31-1/8˝ x 35-1/2˝ (131 cm x 79 cm x 90 cm)
Net Weight
86 lbs (39 kg)
Convenient
solution for
material
transport
on job sites
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and
Charger Sold Separately.
Support Foot (2 Ea. 144675-6),
Key (643890-4),
Wrench 13 (2 Ea. 781006-4),
Bucket (198494-2)
DCU180ZX2
with Bucket
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Support Foot (2 Ea. 144675-6), Key (643890-4),
Wrench 13 (2 Ea. 781006-4), FlatbedTray (199116-7)
DCU180ZX1
with Flatbed Tray
18V x2 LXT POWER-ASSISTED
WHEELBARROW ACCESSORIES
FLATBED TRAY
199116-7
BUCKET
198494-2
Description
• Easy four bolt installation and removal
• Side rails install in up or down position;
large knob for easy adjustment
• Ideal for loading heavy duty bulky
material such as bricks, concrete
bags and more
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Flatbed Tray
• Easy four bolt installation
and removal
• Heavy duty steel based bucket
for tough workloads
• Ideal for transporting material
on job sites
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Bucket
