EA4300FREC

STANDARD EQUIPMENT INCLUDES:

.325˝ Chain 18" 50G (512 484 672), 18˝ Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (419560-5),

Spike Bar (346301-5), Universal Wrench (782026-1),Torx Wrench (782025-3), Screwdriver (for CarburetorAdjustment) (783012-5),

Spark Plug (0650109950)

18˝ Bar

• Catalytic converter reduces engine emissions for

reduced environmental impact

• Throttle-lock start position with decompression

valve for reduced start up force

• External access holes allow easy

carburetor adjustment

• Primer pump for easy starting

• Automatic chain oiler

• Inertia chain brake

Rapid Start

18˝ / 43 cc 2-Stroke Chainsaw

SPECIFICATIONS

Displacement

42.4 cc (2.6

cu.in.

)

Chain Pitch / Gauge

.325˝ / .050˝

Maximum Engine Speed 13,500 RPM

Power Rating

2.1kW / 2.9 hp

Fuel / Oil Mixture (Makita Oil)

50:1

Fuel Tank Capacity

480 ml

Oil Tank Capacity

280 ml

Net Weight: Dry w/o Bar & Chain

10.8 lbs (4.9 kg)

EA4300

EA3501SRDB

STANDARD EQUIPMENT INCLUDES:

16˝ Guide Bar (165202-6), 16˝ Chain Chain (531 492 656), Chain Cover 14”-16” (419560-5), Spike Bar (346301-5),

Universal Wrench (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)

16˝ Bar

• Touch & Stop Switch automatically returns switch

to start position, eliminating carburetor flooding

• Intelligent Ignition Coil controls stable idling,

increases output power, protects against engine

overrun and enables easier restarting

• Toolless Chain Tension Adjustment for quick and

easy adjustment on the jobsite

• Throttle-Lock Start Position

• External access holes allow easy

carburetor adjustment

• Primer pump for easy starting

• Automatic Chain Oiler

• Inertia Chain Brake

16˝ / 35 cc 2-Stroke Chainsaw

SPECIFICATIONS

Displacement

35 cc (2.1

cu.in

)

Chain Pitch / Gauge

3/8˝ / .050˝

Maximum Engine Speed 13,100 RPM

Power Rating

1.7 kW / 2.3 hp

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Oil Tank Capacity

290 ml

Net Weight: Dry w/o Bar & Chain

9.9 lbs (4.5 kg)

EA3201SRDB

STANDARD EQUIPMENT INCLUDES:

16˝ Guide Bar (165202-6), 16˝ Chain (531 492 656), Chain Cover 16˝ (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),

Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)

16˝ Bar

• Touch & Stop Switch automatically returns switch

to start position, eliminating carburetor flooding

• Intelligent Ignition Coil controls stable idling,

increases output power, protects against engine

overrun and enables easier restarting

• Toolless Chain Tension Adjustment for quick and

easy adjustment on the jobsite

• Throttle-Lock Start Position

• External access holes allow easy carburetor

adjustment

• Primer pump for easy starting

New colour for safety

high visibility

16˝ / 32 cc 2-Stroke Chainsaw

SPECIFICATIONS

Displacement

32 cc (1.95

cu.in

Chain Pitch / Gauge

3/8˝ / .050˝

Maximum Engine Speed 12,800 RPM

Power Rating

1.35 kW / 1.8 hp

Fuel / Oil mixture

50:1

Fuel Tank Capacity

400 ml

Oil Tank Capacity

280 ml

Net Weight: Dry w/o Bar & Chain

9.4 lbs (4.2 kg)

All Makita

Gasoline Powered Chainsaws

now feature

New

HIGH VISIBILITY SAFETY COLOUR!

New colour for safety

high visibility

DUC353Z

14˝ / 18Vx2 LXT Cordless Chainsaw

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Guide Bar Length

14˝ (350 mm)

Chain Pitch / Gauge

3/8˝ / 0.043˝

Chain Speed

0-3,940 FPM (0-1 200 m/min)

Overall Length

30-1/2˝ (773 mm)

Net Weight

8.9 lbs (4.0 kg)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

14" Chain (196741-5), 14" Guide Bar (165246-6), Chain Cover (419288-5),

Spike Bumper (347078-5), Oil Supply (182229-1)

makita.ca

DUC353Z

Variable Speed

Fast Chain Speed of

3,940 Feet Per Minute!

DUC353Z

High Power & Chain Speed equivalent

to a 30 cc Gasoline Chainsaw

• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed

equivalent to a 30 cc Gasoline Chainsaw

• eXtreme Protection Technology (XPT) offers maximum protection against

dust, debris and liquids for optimal performance in extreme conditions

• Variable Speed Trigger Switch (0 - 3,940 FPM) for Easy Operation

• Built-in LED On / Off Switch with Auto Power-Off function for Extended Battery Life

Unique Battery Positioning for

Optimum Performance

Brushless Outer

Motor Direct

Drive System
