1" Cordless Rotary Hammer

Lightweight 3-Mode Rotary Hammer

Hammer And Rotation / Hammer Only / Rotation Only Features Quick Change Drill Chuck

SDS-PLUS Shank

Variable Speed, Reversible

Center of Gravity located close to rear handle resulting in ideal tool balance during operation
Torque Limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
Rubber Housing Bumper protects mode selector switch and gear housing from damage
LED light with Afterglow feature
One Touch Sliding Chuck enables quick and easy bit change
Sliding Rear Handle for increased vibration absorption
Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Includes BCV02 18V to 36V Li-Ion Battery Converter enabling use with 2 x 18V Li-Ion Batteries

Where to buy

Items Included:Batteries and Charger Sold Separately. Grip (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Drill Chuck Set (194079-2), Direct Connect Battery Converter, Tool Bag (831271-6)

158057-6

443122-7

194683-7

324219-0

194079-2

Images shown may not represent the full listing or the true size of included items.

Center of Gravity located close to rear handle resulting in ideal tool balance during operation
Torque Limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
Rubber Housing Bumper protects mode selector switch and gear housing from damage
LED light with Afterglow feature
One Touch Sliding Chuck enables quick and easy bit change
Sliding Rear Handle for increased vibration absorption
Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Includes BCV02 18V to 36V Li-Ion Battery Converter enabling use with 2 x 18V Li-Ion Batteries

Items Included: Batteries and Charger Sold Separately. Grip (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Drill Chuck Set (194079-2), Direct Connect Battery Converter, Tool Bag (831271-6)

Shipping Dimensions (Length x Width x Height) & Weight : 21.46 In. X 11.61 In. X 7.28 In. Weight : 14.9 Lb.

Specifications

Battery	36V (2.6 Ah) Li-Ion
Capacities:
Concrete	1” (26 mm)
Steel	1/2” (13 mm)
Wood	1-1/4" (32 mm)
No Load Speed	0 – 1,200 RPM
Blows Per Minute	0 – 4,800 BPM
Impact Energy	3.0 J (2.2 ft. lbs)
Vibration Level	15.0 m/s²
Noise Level	92 dB
Overall Length	15-1/4” (387 mm)
Net Weight	7.7 lbs (3.5 kg)
Shipping Weight	14.9 lbs (6.8 kg)
